Delphi Weather-Pack Automotive Connector 12010996 (1 Pin, Male, Crimp Termination)

Delphi Weather-Pack Sealed Female Automotive Connector Assemblies.

Description

Product Details

Weather-Pack sealed female automotive connector assemblies with triple ribbed silicone connector and cavity seals designed to withstand extreme temperatures, chemicals and fluids. The terminals of these Weather-Pack automotive connectors are tin plated and have special core wings that allow crimp only connections so solder is not needed, the dual tangs on the terminals help prevent backing out. These Weather-Pack automotive connectors have positive locking indexing to prevent mismating.

Typical applications for these Weather Pack sealed automotive connectors are low energy, low voltage automotive applications in harsh environments such as commercial vehicle and marine applications.

Specifications

Series Weather-Pack
Part Number 12010996
Number of Contact 1
Gender Male
Current Rating 20 A
Mounting Type Cable Mount
Termination Method Crimp
Colour Black
Width 16.5 mm
Height 17.3 mm
Depth 47.6 mm
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +125 °C
